UNIVIEW Prime Series 32CH AI Network Video Recorder 16MP 320Mbps 2-SATA HDD NVR502-32B-P16

Overview

The UNIVIEW Prime Series NVR502-32B-P16 delivers advanced 32-channel network video recording with support for up to 16MP resolution and 320Mbps incoming bandwidth. Engineered for high-performance surveillance, this unit features dual SATA interfaces supporting up to 16TB per disk for extensive storage capacity. The system incorporates UNV 3.0 technology for enhanced video management and includes H.265 compression to optimise storage efficiency without compromising image quality. Built-in AI capabilities enable intelligent video analysis including vehicle and human detection. The robust metal chassis ensures reliable operation in demanding environments while maintaining low power consumption.

Model	NVR502-32B-P16
Video Input Channels	32-ch
Max Resolution	16MP
Incoming Bandwidth	320Mbps
Outgoing Bandwidth	160Mbps
Storage Interfaces	2 x SATA
Max Storage Capacity	16TB per disk
Video Compression	H.265, H.264
Network Interfaces	2 x RJ45 10M/100M/1000M
USB Interfaces	2 x USB 3.0, 1 x USB 2.0
Power Supply	12V DC, 3A
Dimensions	380mm x 275mm x 53mm
Weight	2.5kg (without HDD)
Operating Temperature	-10°C to +55°C
Certification	CE, FCC, UL, RoHS
