UNIVIEW Network Control Keyboard 4D Joystick LCD Display IP Interface KB-1100

Overview

The UNIVIEW KB-1100 Network Control Keyboard delivers precise surveillance management through its 4-dimensional joystick and integrated LCD screen. Designed for IP network environments, this controller facilitates seamless operation of PTZ cameras and NVR menus. The unit supports multiple user permissions and device connections, ensuring flexible access control for complex security setups. Its ergonomic layout includes dedicated function keys for rapid command execution, while the RS-485 and RS-232 serial interfaces allow integration with legacy systems. Constructed for durability, the keyboard operates reliably across a wide temperature range, making it suitable for control rooms and monitoring stations requiring continuous uptime.

Model	KB-1100
Joystick Type	4-Dimensional
Display	LCD Screen
Network Interface	1 RJ-45 10M/100M Adaptive Ethernet
USB Interface	1 USB 2.0
Serial Interface	1 RS-232, 2 RS-485
Power Supply	12V DC
Power Consumption	5W
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Dimensions	470mm x 270mm x 440mm
Weight	< 1kg
