UNIVIEW 24-Port 10/100Mbps PoE 2-Gigabit Combo Unmanaged Switch NSW2000-24T2GC-POE

Overview

The Uniview NSW2000-24T2GC-POE is a 24-port Fast Ethernet switch designed for reliable video surveillance networks. It provides 24 PoE ports delivering up to 30W per port and 2 Gigabit combo uplinks for high-speed data transmission. The unit supports IEEE 802.3af/at standards and features an EXTEND mode to increase transmission distance up to 250m for specific camera applications. Housed in a durable metal casing, this plug-and-play switch requires no configuration, making it ideal for small to medium business security installations.

PoE Ports	24 x 10/100Mbps
Uplink Ports	2 x Gigabit Combo (RJ45/SFP)
PoE Standard	IEEE 802.3af/at
Max PoE Power	30W per port
Total PoE Budget	400W
Switching Capacity	8.8Gbps
Packet Forwarding Rate	6.55Mpps
MAC Address Table	4K
Power Consumption	7.65W (without PoE load)
Input Voltage	100-240V AC, 50/60Hz
Operating Temperature	0°C to 40°C
Dimensions	440 x 220 x 44 mm
Weight	3.5 kg
Material	Metal
Warranty	3 Years
