HILOOK NVR-216MH-C/16P(D) 16 Channel 4K PoE NVR 2x SATA HDD Slots Network Video Recorder

14-Day Returns Policy. No Hassle.

Australian Warranty and Tech Support

Official Online Reseller with real support from brands

HILOOK

HILOOK 16 Channel 4K PoE NVR 2x SATA HDD Slots Network Video Recorder NVR-216MH-C/16P(D)

Name: HILOOK 16 Channel 4K PoE NVR 2x SATA HDD Slots Network Video Recorder NVR-216MH-C/16P(D)
Brand: HILOOK
SKU: NVR-216MH-C16P(D)
Price: 343.0 AUD
Availability: InStock

~~$376.00 AUD~~ $343.00 AUD Sale

Shipping calculated at checkout.

This price is GST-exclusive

Product variants

Quantity

Payment

Know more about this product

The HiLook NVR-216MH-C/16P is a robust 16-channel network video recorder designed for professional surveillance and commercial environments. Featuring 16 built-in PoE ports, this unit delivers plug-and-play connectivity for up to 16 IP cameras, eliminating the need for external switches. It supports 4K Ultra HD output via HDMI, ensuring crystal-clear video playback and real-time monitoring. The device utilises H.265+ compression technology to optimise bandwidth usage and storage efficiency without compromising image quality. Two internal SATA bays allow for scalable storage up to 20TB (10TB per drive), accommodating extended recording retention periods. Equipped with smart detection capabilities, the NVR identifies motion, line crossing, and intrusion events to trigger alerts. Remote management is seamless through the HiLookVision app or desktop software, providing full system control from any location. The unit operates on a standard 100V–240V power supply and maintains functionality in temperatures ranging from -10°C to +55°C.

Key Features & Technical Specifications

Feature	Specification
Model	NVR-216MH-C/16P
Video Input	16 IP Channels (Built-in PoE)
Max Decoding	2 channels @ 8MP or 4 channels @ 4MP or 8 channels @ 1080p
Incoming Bandwidth	160 Mbps
Outgoing Bandwidth	80 Mbps
Video Output	1x HDMI (up to 4K), 1x VGA (up to 1080p)
Audio Output	1 channel (RCA)
Two-Way Audio	1 channel (RCA)
Compression Format	H.265+, H.265, H.264+, H.264
SATA Interface	2x SATA (up to 10TB per HDD)
USB Ports	2x USB 2.0
Power Supply	100V–240V AC, 50/60Hz
Power Consumption	≤ 20W (without HDD or PoE)
Working Temperature	-10°C to +55°C
Humidity	10% to 90% (non-condensing)
Dimensions	385 x 315 x 52 mm
Weight	≤ 3 kg (without HDD)

How to use this product - from Virtus experts

These guides are created by our experts with years of real-world security surveillance experience. Get a free project quote tailored to your needs — contact our team at Virtus Electronics today.

Ideal Use Cases

Small office or retail recorder hub: The HILOOK NVR-216MH-C/16P(D) is a network video recorder for IP camera systems with 16CH channels. Use it as the central recording and playback unit for Australian shopfront and office installs.

Residential multi-camera homes: Pair with matching brand IP cameras on a PoE switch or the NVR PoE ports where fitted. Plan storage around retention days, not just camera count.

Retrofit from older DVR sites: When moving to IP, keep camera and NVR brands aligned for full feature support (smart events, firmware, plugins).

Compact PoE installs: Listed PoE ports: 16 ports. Budget PoE class per camera and leave headroom on the NVR/switch.

Buyer Tips

Confirm HDD bay vs HDD included. Do not assume a drive is inside the box unless this listing explicitly says so.
Size storage for retention. Calculate TB from camera count × resolution × days retained, then pick surveillance-rated HDDs.
Match PoE budget. If using built-in PoE, leave spare wattage; otherwise use a separate PoE switch.
Keep firmware current. Update NVR and cameras together after install so smart events stay stable.

FAQs

1. Does this NVR include a hard drive?

Listing note: HDD included. Many NVRs ship as recorder-only with HDD bays — confirm “HDD included” vs “HDD bay” on this page before quoting storage.

2. How many cameras can it record?

Channel rating on this listing: 16CH. Do not exceed the published channel/bandwidth limits; check resolution per channel on the datasheet.

3. Is it compatible with mixed camera brands?

Basic RTSP/ONVIF may work, but smart events and full UI features are most reliable with the same brand cameras. Prefer matched HILOOK cameras for this unit.

4. Where should it be installed?

Keep the NVR indoors, ventilated, and on a UPS if the site needs continuous recording through short outages.
