DAHUA 10-Port 8 PoE 2 Gigabit Uplink 90W Unmanaged PoE Switch DH-S3010-8ET2GT-90
DAHUA 10-Port 8 PoE 2 Gigabit Uplink 90W Unmanaged PoE Switch DH-S3010-8ET2GT-90
DAHUA 10-Port 8 PoE 2 Gigabit Uplink 90W Unmanaged PoE Switch DH-S3010-8ET2GT-90
DAHUA 10-Port 8 PoE 2 Gigabit Uplink 90W Unmanaged PoE Switch DH-S3010-8ET2GT-90
Know more about this product
Description
The Dahua DH-S3010-8ET2GT-90 is a reliable 10-port unmanaged desktop PoE switch engineered to streamline power delivery and data transmission for small to medium IP surveillance systems. It features eight 10/100 Mbps PoE ports compliant with IEEE 802.3af and IEEE 802.3at standards, delivering up to 30 W per port alongside a combined 90 W power budget. Two dedicated Gigabit RJ45 uplink ports ensure high-speed, bottleneck-free connectivity to your network video recorder (NVR), core router, or upstream network switch.
Equipped with an extended-range mode, this network switch can transmit data and power across ports 1 through 8 up to a distance of 250 metres at 10 Mbps, making it an excellent solution for cameras deployed in distant corridors, perimeter fences, or separate outbuildings. Built-in 6 kV common mode lightning protection and robust electrostatic discharge protection safeguard connected hardware against electrical surges in demanding deployment environments.
Engineered with a durable, fanless sheet-metal enclosure, the switch delivers completely silent operation and reliable heat dissipation while reducing dust intake and maintenance requirements. Its true plug-and-play architecture requires no web configuration or VLAN setup, providing effortless desktop or wall-mounted deployment for homes, retail storefronts, offices, and small warehouse installations.
| Brand | Dahua |
| Model Number | DH-S3010-8ET2GT-90 |
| Product Type | 10-port unmanaged desktop PoE switch |
| PoE Ports | 8 × RJ45 10/100 Mbps |
| Uplink Ports | 2 × RJ45 10/100/1000 Mbps Gigabit |
| Total PoE Budget | 90 W |
| Maximum PoE per Port | 30 W |
| PoE Standards | IEEE 802.3af, IEEE 802.3at |
| PoE Pin Assignment | Pins 1, 2, 4, 5 (+) / Pins 3, 6, 7, 8 (-) |
| Long-Distance PoE | Up to 250 m at 10 Mbps (Ports 1–8) |
| Switching Capacity | 5.6 Gbps |
| Packet Forwarding Rate | 4.168 Mpps |
| Packet Buffer | 1 Mbit |
| MAC Address Table | 2K entries |
| Jumbo Frame | 9216 bytes |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Power Supply | External 53 V DC, 1.81 A |
| Power Consumption | Idle: 2.1 W / Full Load: 94.2 W |
| Surge Protection | Lightning 6 kV Common Mode / 1 kV Differential Mode; ESD 8 kV Air / 6 kV Contact |
| Operating Temperature | -10°C to 55°C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Enclosure Material | Sheet-metal housing (fanless) |
| Installation Type | Desktop or wall mount |
| Dimensions | 184.6 mm × 77.4 mm × 27 mm |
| Weight | 0.3 kg |
| Certifications | CE |
